| Place of Origin: | Guangdong, P.R.C. |
| Brand Name: | Basda Medical |
| Certification: | ISO9001, ISO13485 |
| Model Number: | BMP-15B |
| Minimum Order Quantity: | 10 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1 unit/carton, 345mm*310mm*380mm |
| Delivery Time: | Various by Logistics and Custom |
| Payment Terms: | Credit card, Paypal, T/T, Western Union, MoneyGram |
| Supply Ability: | 3 Days per 10 Units |
| Apply For: | ECG, RESP, 2TEMP, PR, 2IBP, NIBP, SPO2, CO2 | Product Name: | Vital Sign Monitor |
|---|---|---|---|
| Lead: | 5 | After Sale Support: | Online Technical Support Or Replacement |
| Machine Size: | 400*190*310mm | Thermal Paper: | 50 Mm*30m |
| High Light: | 15Inch Multi Parameter Patient Monitor,IBP Multi Parameter Patient Monitor,15Inch Patient Cardiac Monitor |
||
Technical Specifications
ECG
Connection mode: Five-cable electrocardiograph input( R, L, F, N ,C )
Connection method: I, II, III, AVR,AVL,AVF,V1-V6
Number of display waveform: 7
Gain options: 0.25mm/mV, 0.5mm/mV, 1mm/mV, 2mm/mV, 4mm/mV, Auto
Input impedance: ≥5MΩ
The ratio of the total mold represses: ≥100dB
Frequency response: Filter 0.5-40Hz (±3dB)
Protection: Isolation from voltage 4000 VAC and 50HZ±1HZ and protection against interference from defibrillation,
high-frequency electro tome, alternative current, muscle electricity and floating.
Alarm when electrode falls off: Yes
Scan speed: 25mm/s, 50mm/s
Heart Rate
Measuring range: 0-300 bpm
Accuracy: ±1bpm
Break time: once per pulse
Alarm system: Audio-video alarm
Non-Invasive Blood Pressure
Measuring method: self-oscillation method
Operation mode: Single time (Manual), Period (Auto)
Measuring parameters: Systolic pressure/ Diastolic pressure
Measuring pattern: Adults and Children
Measuring range: Adult: 0~300mmHg, Child: 0-200mmHg
Pressure unit: mmHg/ Kpa
Alarm system: Audio-video alarm
Temperature
Type: Double road (the optional install)
Measurement range: 0-50 ℃
Unit: ℃/℉
Resolution: 0.1℃
Alarm range: 0~50℃
Alarm system: Audio-video alarm
SPO2
Display: Number of SPO2, waveform of capacity, pulse
Measurement Range: 0~100%
Resolution: 1%
Accuracy: 70~100% (±2%)
Type of the sensor: LED w/double wave length.
Pulse rate range: 0-300bpm
Alarm system: Audio-video alarm
Respiration
Display: waveform, respiratory rate
Measurement Range: 0-120 breaths/ minute
Operation mode: Chest resistance
Measuring accuracy:±2 breaths/ minute
Scan speed: 25mm/s, 50mm/s
Alarm system: Audio-video alarm
System Output
Display Type: 12.1 inch LCD with TFT 800x600
Trand diagram: 150 hours
Recorder: Recorder could be optional install
Network: could be connected to central machine
Power Supply
AC220V±22V, 50Hz±1Hz
Protection Degree: Class II,Type BF
Accessories
| Items | Unit |
| Reusable ECG Leadwires | 1 |
| LNOP Reusable SpO2 Sensor | 1 |
| NIBP Hose | 1 |
| Blood Pressure Cuffs | 1 |
| Fuse | 2 |
| ECG Electrodes | 1 |
| Temperature Trunk Cables | 2 |
| Power Cord | 1 |
| Grounding Cable | 1 |
| ECG Recording Paper | 1 |
