Place of Origin:	Guangdong, P.R.C.
Brand Name:	Basda Medical
Certification:	CE, ISO
Model Number:	BMP-9000JA

Minimum Order Quantity:	10
Price:	Negotiable
Packaging Details:	1 unit/carton, 345mm310mm380mm
Delivery Time:	Various by Logistics and Custom
Payment Terms:	Credit card, Paypal, T/T, Western Union, MoneyGram
Supply Ability:	3 Days per 10 Units

Display:	12.1-inch Colour TFT	Parameters:	5 Lead ECG, SpO2(F-5), NIBP, TEMP, RESP, PR, HR
Dimension:	370210430mm Size	Gross Weight:	5.5 Kg
Trace:	9 Waveforms (7 ECG, 1 SPO2 And 1 RESP)	ECG Mode:	5-ead(R,L,F,N,C)
High Light:	9 Waveforms Portable Patient Monitor , 210BPM Portable Patient Monitor , ECG NIBP Portable Patient Monitor

Display	12.1”color TFT Rolling and refreshing waveform display Resolution: 800×600 Multi display selectable including: Large-font display Trend coexist display OxyCRG dynamic view display. Bed-to-bed view display
Trend	Parameter graphic and tabular trends: 5s/piece, 8 hours; 1min/piece,168 hours(24hour×7days) 5min/piece,1000 hours.
Storage	NIBP: 1000 groups Alarm: 200 groups Full disclosure waveforms: 3600S
Battery	Rechargeable lead acid cell, 12v/4AH Max.24 hour for charging, 4 hours for continue working
Alarm	User-adjustable High, Medium and Low limits 3-level Audible and visual alarm
Indicator	Power/battery indicator light QRS beep and alarm sound
Networking	Connected to central monitoring system TCP/IP netting platform
Trace	9 waveforms(7 ECG, 1 SPO2 and 1 RESP) Sweep speed:12.5mm/s,25mm/s,50mm/s
Recorder	Build-in, thermal array Plethysmogram caveform:2 channels Record mode: manual, on alarm, time-defined Recording width: 50mm Printing speed: 50mm/s
Recording type	Frozen waveform record NIBP recall record Trend table record Alarm record Fixed -time record

Parameters	Technical Specifications
ECG	Lead mode: 5 –lead(R,L,F,N,C) Lead selection : I, II, III, avR, avL, avF, V Waveform: 3 and 7 channel selectable Gain selection: 0.5mm/mv,1mm/mv,2mm/mv Sweep speed: 12.5mm/s;25mm/s;50mm/s Heart rate range: Adult: 15~300bpm; Neonate/pediatric:15~350bpm Accuracy: +1bpm or +1%,whichecer is greater Resolution: 1bpm Filter: surgery mode:1~20Hz monitor model:0.5~40Hz Diagnostic mode:0.05~130Hz Scaling signal: 1mv,+3% Protection: withstand 4000VAC/50 voltage isolation against electrosurgical interference and defibrillation Alarm range: 15~350bpm S-T segment detection: Measurement range: 2.0mV~+2.0mV Alarm Range: -2.0mV~ +2.0mV Accuracy: -0.8mV ~+0.8Mv Error: +0.02Mv
Respiration	Method: Thoracic impedance Measurement range: Adult:7~120rpm; Neonate/Pediatric:7~150rpm Apnea alarm: YES,10~40s Resolution: 1rpm Accuracy: +2rpm
FHR	Transducer: Multi-crystal, Pulsed Doppler Measurement range: 50~210BPM Working frequency: 1 MHz Strength: <5mW/cm² Signal processing: special DSP system and modern recognization. Resolution: 1BPM Accuracy: ±1BPM Alarm Range: High: 160,170,180,190 BPM, Low: 100,110,120 BPM
TOCO Measuring	Manual button marking, automatic FM identifying function
EtCO2 (Sidestream CO2)	Measurement range: 0~99mmHg Accuracy: +2mmHg (0~40mmHg) Sampling Range: 100ml/min Sampling rate accuracy: 15% Respiration rate: 0~120rmp Respiration accuracy: +2rmp (0~70rmp) +5rmp (>70rmp) Respiration time: <240msec (10% to 90%) Delay time: <2s
EtCO2 (Mainstream CO2)	Method: Infrared Spectrum Range: 0.0-10% (0~76%) Resolution: 1mmHg (0.1%) Accuracy: ＜5%(±4.0 mmHg) Or＜10%(of Readings)
Recorder	Build-in, thermal array Plethysmogram caveform:2 channels Record mode: manual, on alarm, time-defined Recording width: 50mm Printing speed: 50mm/s Recording type: Frozen waveform record NIBP recall record Trend table record Alarm record Fixed -time record
Scan Speed for ECG Waveform is adjustable	12.5mm/s accuracy ±10% 25mm/s accuracy±10% 50mm/s accuracy±10%
NIBP	Method: Digital Automatic oscillometric Operation mode : Manual/Automatic/continuous Auto measurement time: Adjustable(1~480min) Measurement Unit: mmHg/Kpa selectable Measurement types: Systolic, Diastolic, Mean Measurement range: Range of Systolic pressure: Adult: 40~270mmHg Pediatric: 40~220mmHg Neonate: 40~135mmHg Range of mean pressure: Adult: 20~235mmHg Pediatric: 20~165mmHg Neonate: 20~110mmHg Range of diastolic pressure: Adult: 10~215mmHg Pediatric: 10~150mmHg Neonate :10~100mmHg Over-pressure protection: Double safety protection Resolution: 1 mmHg Alarm: Systolic, Diastolic, Mean
Resolution	Pressure 1mmHg Cuff Pressure ±3 mmHg Accuracy ±10% or ±8mmHg, which is greater Over-pressure Protection: Adult Mode 315±10 mmHg Pediatric Mode 265±10 mmHg Neonatal Mode 155±10 mmHg
SPO2	Measurement range: 0~100% Resolution: 1% Accuracy: +2%(70-100%);0-69% unspecified Arrhythmia analysis: YES Alarm range 0~100% Pulse Rate: range: 20~300bpm Resolution: 1bpm Error: +1bpm or +2%,whichever is greater
Pulse Rate(PR)	Measuring and Alarm Range 0~250bpm Resolution 1bpm Measuring Accuracy ±2bpm or ±2%, which is greater Alarm Accuracy ±2bpm
TEMPERATURE	Compatible probe: YSI or CYF Measurement range: 5~50℃ Resolution : 0.1℃ Accuracy: +0.1℃ Refreshing time: about 1 Average measuring time: <10s
IBP	Channel: 2 channels Range: -50-300mmHg Resolution: 1mmHg Accuracy: ±4mmHg(±4%) Unit: mmHg, Kpa Converter Sensitivity: 5mV/V/mmHg Transducer sites: ART/PA/CVP/LAP/RAP/ICP
