| Place of Origin: | Guangdong, P.R.C. |
| Brand Name: | Basda Medical |
| Certification: | ISO9001, ISO13485 |
| Model Number: | BMP-12B |
| Minimum Order Quantity: | 10 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1 unit/carton, 345mm*310mm*380mm |
| Delivery Time: | Various by Logistics and Custom |
| Payment Terms: | Credit card, Paypal, T/T, Western Union, MoneyGram |
| Supply Ability: | 3 Days per 10 Units |
| Screen Size: | 12in Large | Parameters: | 6 Vital |
|---|---|---|---|
| Function: | Vital Sign | After Sale Support: | Online Technical Support |
| Dimension: | 330*180*310mm Size | Net Weight: | 4.82 Kg Weight |
| High Light: | 12in Screen Patient Monitoring Machine,ISO13485 Patient Monitoring Machine,CMRR Vital Sign Machine |
||
| Parameters |
Technical Specifications |
| ECG |
Lead Mode 3-lead and 5-lead are optional Lead Selection I, II, III, AVR, AVL, AVF, V Wave 5-lead: 2 channels 3-lead: 1channel Gain ×2.5mm/mV, ×5.0mm/mV, ×10mm/mV, ×20mm/mV |
| CMRR |
Monitor ≥ 100 dB Surgery ≥ 100 dB Diagnosis ≥ 60 dB |
| Bandwidth | Surgery 1 ~ 20 Hz(+0.4dB,-3dB) Monitor 0.5 ~ 40 Hz(+0.4dB,-3dB) Diagnosis 0.05~75Hz(+0.4dB,-3dB); 76Hz~150Hz(+0.4dB,-4.5dB) Calibration Signal 1 mV (Vp-p), ±5% Accuracy |
| ST Segment Monitoring | Measuring and Alarm Range -0.6 mV~ + 0.8 mV |
| ARR | ARR Detecting Type ASYSTOLE, VFIB/VTAC, COUPLET, BIGEMINY, TRIGEMINY, R ON T, VT>2, PVC, TACHY, BRADY, MISSED BEATS, PNP, PNC |
| Alarm | Available |
| Review | Available |
| Scan Speed for ECG Waveform is adjustable | 12.5mm/s accuracy ±10% 25mm/s accuracy±10% 50mm/s accuracy±10% |
| NIBP | Method Oscillometry Mode Manual, Auto, continuous Measuring Interval in AUTO Mode 1 /2 /3 /4 /5/ 10/ 15/ 30 /60 /90/120/240/480/960 Min Measuring Period in Continuous Mode 5 Min Measuring and Alarm Range 10~270mmHg Alarm Type SYS, DIA, MEAN |
| Resolution | Pressure 1mmHg Cuff Pressure ±3 mmHg Accuracy ±10% or ±8mmHg, which is greater Over-pressure Protection: Adult Mode 315±10 mmHg Pediatric Mode 265±10 mmHg Neonatal Mode 155±10 mmHg |
| SPO2 | Measuring Range 0 ~ 100 % Alarm Range 0 ~ 100 % Resolution 1 % Accuracy 70% ~ 100% ±2% 0% ~ 69% unspecified |
| Pulse Rate(PR) | Measuring and Alarm Range 0~250bpm Resolution 1bpm Measuring Accuracy ±2bpm or ±2%, which is greater Alarm Accuracy ±2bpm |
| TEMP | Channel dual-channel Measuring and Alarm Range 0 ~ 50°C Resolution 0.1°C Accuracy ±0.1°C Actualization Interval about 1 Sec. Average Time Constant < 10 Sec. Alarm responding Time ≤2min |
| IBP | Channel dual-channel Label ART, PA, CVP, RAP, LAP, ICP, P1, P2 Measuring and Alarm Range -50~350 mm Hg Resolution 1 mm Hg Accuracy ±2% or 1mm Hg, which is greater |
What is in the box?
1. Reusable ECG Leadwires----1 set
2. LNOP Reusable SpO2 Sensor----1 set
3. NIBP Hose----1 set
4. Blood Pressure Cuffs----1 set
5. Temperature Trunk Cables----2 sets
6. ECG Electrodes----1 set
7. Fuse----2 sets
8. Power Cord----1 set
9. Grounding Cable----1 set
10. ECG Recording Paper----1 set
11. D-lite++ Patient Spirometry Sets----Optional
